``` ARCHITECTURE DECISION Service type: Deployment Ingress: Yes — public HTTPS endpoint required; TLS termination at ingress layer Scaling: HPA on CPU utilisation (target 65%) + memory (target 75%); min 4 / max 12 replicas Decision notes: - Deployment chosen over StatefulSet: API is stateless; horizontal scaling is safe and expected. - ClusterIP service + Ingress preferred over LoadBalancer to centralise TLS and reduce cloud LB cost. - HPA ceiling at 12 gives ~3× headroom over baseline 4; at 500m CPU request per pod, 12 pods = 6 vCPU capacity ceiling before the scheduler pressure materialises — validate against node pool size. ``` --- **ASSUMPTIONS (stated before generation):** - TLS certificate managed via cert-manager (ClusterIssuer: `letsencrypt-prod`). If you use a pre-provisioned cert, replace the `cert-manager.io/cluster-issuer` annotation with a `tls.secretName` pointing to your existing Secret. - Ingress controller: NGINX (`ingressClassName: nginx`). Adjust if using Traefik, ALB, etc. - Namespace: `production`. Already exists or will be created first (see apply order). - Health check endpoints: `GET /health/live` (liveness) and `GET /health/ready` (readiness). **Confirm these exist in v2.4.1 — if they differ, update probe paths before applying.** - No custom metrics adapter installed; HPA uses standard `cpu` + `memory` resource metrics only. - `DATABASE_URL` and `JWT_SECRET` values are pre-loaded into the cluster as a Secret named `customer-api-secrets`. The manifest creates the Secret shell with placeholder values — **populate before applying** (see Secret manifest notes). --- ```yaml # ============================================================ # RESOURCE 1 — NAMESPACE # ============================================================ apiVersion: v1 kind: Namespace metadata: name: production labels: app.kubernetes.io/managed-by: kubectl environment: production ``` ```yaml # ============================================================ # RESOURCE 2 — CONFIGMAP # Non-sensitive runtime configuration only. # Sensitive values live exclusively in the Secret below. # ============================================================ apiVersion: v1 kind: ConfigMap metadata: name: customer-api-config namespace: production labels: app.kubernetes.io/name: customer-api app.kubernetes.io/version: "v2.4.1" app.kubernetes.io/component: api app.kubernetes.io/part-of: customer-platform environment: production data: # Application runtime settings LOG_LEVEL: "info" PORT: "8080" NODE_ENV: "production" # Health check paths — keep in sync with probe config in Deployment HEALTH_LIVE_PATH: "/health/live" HEALTH_READY_PATH: "/health/ready" ``` ```yaml # ============================================================ # RESOURCE 3 — SECRET # ⚠️ PLACEHOLDER VALUES ONLY. # Do not commit real values to source control. # Populate via: # kubectl create secret generic customer-api-secrets \ # --from-literal=DATABASE_URL='your-dsn-here' \ # --from-literal=JWT_SECRET='your-secret-here' \ # --namespace=production \ # --dry-run=client -o yaml | kubectl apply -f - # Or use an external secrets operator (e.g. External Secrets + Vault / AWS SSM). # ============================================================ apiVersion: v1 kind: Secret metadata: name: customer-api-secrets namespace: production labels: app.kubernetes.io/name: customer-api app.kubernetes.io/version: "v2.4.1" app.kubernetes.io/component: api app.kubernetes.io/part-of: customer-platform environment: production type: Opaque stringData: # ⚠️ Replace these before applying. Never push real values. DATABASE_URL: "REPLACE_BEFORE_APPLY" JWT_SECRET: "REPLACE_BEFORE_APPLY" ``` ```yaml # ============================================================ # RESOURCE 4 — DEPLOYMENT # ============================================================ apiVersion: apps/v1 kind: Deployment metadata: name: customer-api namespace: production labels: app.kubernetes.io/name: customer-api app.kubernetes.io/version: "v2.4.1" app.kubernetes.io/component: api app.kubernetes.io/part-of: customer-platform environment: production annotations: # Enables kubectl rollout history annotation tracking kubernetes.io/change-cause: "Deploy v2.4.1 — initial production rollout" spec: # Baseline replica count. HPA will manage this dynamically. # HPA takes over after first reconciliation; this value is the # floor until HPA has a measurement. replicas: 4 selector: # ⚠️ Selector is immutable after creation — label set is intentionally # minimal here (name only) to avoid selector conflicts if labels evolve. matchLabels: app.kubernetes.io/name: customer-api strategy: type: RollingUpdate rollingUpdate: # maxSurge: allows 1 extra pod above desired during rollout # — ensures capacity is not reduced while new pods initialise. maxSurge: 1 # maxUnavailable: 0 — zero downtime; no pod is taken down # until a replacement passes its readiness probe. # At 4 replicas this means rollout creates pod 5 first, waits # for ready, then terminates pod 1, etc. maxUnavailable: 0 template: metadata: labels: # Template labels MUST include the selector label set. app.kubernetes.io/name: customer-api app.kubernetes.io/version: "v2.4.1" app.kubernetes.io/component: api app.kubernetes.io/part-of: customer-platform environment: production annotations: # Forces pod restart on ConfigMap change when using Reloader # or similar controller. Remove if not using one. configmap.reloader.stakater.com/reload: "customer-api-config" spec: # Graceful shutdown: allow in-flight requests to drain before SIGKILL. # Should be >= your longest expected request timeout + buffer. terminationGracePeriodSeconds: 30 # Spread pods across nodes and availability zones. topologySpreadConstraints: - maxSkew: 1 topologyKey: kubernetes.io/hostname whenUnsatisfiable: DoNotSchedule labelSelector: matchLabels: app.kubernetes.io/name: customer-api - maxSkew: 1 topologyKey: topology.kubernetes.io/zone whenUnsatisfiable: ScheduleAnyway # soft constraint; adjust to DoNotSchedule if AZ spread is mandatory labelSelector: matchLabels: app.kubernetes.io/name: customer-api # Security hardening: drop all Linux capabilities at pod level. securityContext: runAsNonRoot: true runAsUser: 1000 runAsGroup: 1000 fsGroup: 1000 seccompProfile: type: RuntimeDefault containers: - name: customer-api image: company/customer-api:v2.4.1 # Never use `latest` — pinned to v2.4.1 as required. imagePullPolicy: IfNotPresent ports: - name: http containerPort: 8080 # Must match PORT in ConfigMap and Service targetPort protocol: TCP # ── RESOURCE ENVELOPE ───────────────────────────────────────── resources: requests: cpu: "500m" memory: "512Mi" limits: cpu: "1000m" # 1 vCPU memory: "1Gi" # ── END RESOURCE ENVELOPE ───────────────────────────────────── # ── ENVIRONMENT — NON-SENSITIVE (ConfigMap) ─────────────────── envFrom: - configMapRef: name: customer-api-config # ── ENVIRONMENT — SENSITIVE (Secret, injected individually) ── env: - name: DATABASE_URL valueFrom: secretKeyRef: name: customer-api-secrets key: DATABASE_URL - name: JWT_SECRET valueFrom: secretKeyRef: name: customer-api-secrets key: JWT_SECRET # ── END ENVIRONMENT ──────────────────────────────────────────── # ── PROBES ──────────────────────────────────────────────────── # LIVENESS: restarts the container if it deadlocks / hangs. # Deliberately lenient — avoid restart loops on slow startups. livenessProbe: httpGet: path: /health/live port: http # references the named port above initialDelaySeconds: 20 # give the app time to start periodSeconds: 15 timeoutSeconds: 5 failureThreshold: 3 # 3 consecutive failures = restart successThreshold: 1 # READINESS: removes pod from Service endpoints until ready. # Stricter timing than liveness — gates real traffic. readinessProbe: httpGet: path: /health/ready port: http initialDelaySeconds: 10 periodSeconds: 10 timeoutSeconds: 3 failureThreshold: 3 successThreshold: 1 # STARTUP: gives slow-starting containers time before liveness kicks in. # 30 × 10s = 300s maximum startup window. startupProbe: httpGet: path: /health/live port: http initialDelaySeconds: 5 periodSeconds: 10 failureThreshold: 30 successThreshold: 1 # ── END PROBES ──────────────────────────────────────────────── # Container-level security hardening securityContext: allowPrivilegeEscalation: false readOnlyRootFilesystem: true capabilities: drop: - ALL # Writable scratch space if the app writes temp files. # Remove if readOnlyRootFilesystem causes issues and app
