For a 100 Ah NCM prismatic cell targeting ~200 Wh/kg: 1. Cathode loading: NCM specific capacity ≈ 200 mAh/g. With areal loading of 3.5 mAh/cm², you need ~100,000 cm² of double-sided coated cathode area. 2. Electrode stack: ~50–60 layers (cathode + anode + separator pairs), each ~150 cm × 30 cm usable area. 3. N/P ratio: 1.15 (graphite anode, 360 mAh/g) → anode loading ≈ 4.0 mAh/cm². 4. Cell dimensions (approximate): 148 × 97 × 110 mm (prismatic can), mass ~2.1 kg. 5. Voltage: 3.65 V nominal → energy = 365 Wh → ~174 Wh/kg (cell level). Note: Confirm electrolyte amount (3.0–3.5 g/Ah) and formation protocol (0.05C to 3.6 V, 48 h aging).
